6.3.9.4 LED Current Dimming With External NTC Sensor
When an external resistor for maximum current control is used, current dimming for LED current can be used also. In this case LED current can be de-rated when ambient temperature is high. This option must be enabled by <EXT_TEMP_I_DIMMING_EN> and <EXT_TEMP_COMP_EN> EEPROM bits.
Knee point and slope are defined by <EXT_TEMP_MINUS[1:0]> and <EXT_TEMP_GAIN[3:0]> EEPROM bits respectively. LED shutdown temperature is defined by <EXT_TEMP_LEVEL_HIGH[3:0]> bits. Serial and parallel resistors R1 and R2 affect the slope and knee point and can be used for the thermal curve adjustment and NTC linearization.
Figure 6-25 Current Dimming for High Ambient Temperature
Figure 6-26 NTC LinearizationFigure 6-27 and Figure 6-28 show the block diagrams for current dimming.
Figure 6-27 Temperature-Dependent NTC Current (Subtracted from ISET Current)
Figure 6-28 NTC Current Processing — Scaling, Shift, and LimitationCurrent dimming by external NTC sensor for 150-mA scale can be defined by formulas:
Equation 6.
Equation 7.
ITEMP cannot be negative; if ITEMP < 0, then ITEMP must be 0.
Equation 8. ILED = (ISET – ITEMP) × 150 mA
ILED cannot go below a 5-mA level; if calculated ILED < 5 mA, then ILED = 5 mA.
where
- ISET: Maximum current setting with external resistor RISET, μA
- ITEMP: Temperature compensation, μA
- RISET: External resistor, kΩ
- R1, R2: Resistors for adjustment, kΩ
- ILED: Output current per channel, mA
- EXT_TEMP_MINUS[1:0]: 1, 5, 9, 13 μA
- EXT_TEMP_GAIN[[3:0]: 50/n, n = 16 to 1
- VBG: 1.2 V
