8.5.2 SPI Sequence
Figure 8-22 and Figure 8-23 depict the SPI communication sequence during read and write operations for the TIC12400-Q1.
Figure 8-22 TIC12400-Q1 Read SPI Sequence
Figure 8-23 TIC12400-Q1 Write SPI Sequence
