3.2 AC(T): Advanced CMOS
The AC family is TI's high-drive CMOS logic family supporting over 90MHz operation at 5V with up to 24mA of continuous current per output channel. The AC family contains a full complement of logic gates and registers while also supporting wide bus communications with higher channel count bus drivers. The ACT family has the same high speed and high drive capabilities of the AC family while providing TTL-compatible I/Os when operating from a 5V supply.
| Key Features | Packaging Options |
|---|---|
|
|
| Applications | |
|---|---|
|
 |
