8.2.2.7.1 Small Signal Model
The TPS61378-Q1 uses the fixed frequency peak current mode control. There is an internal adaptive slope compensation to avoid subharmonic oscillation. With the inductor current information sensed, the small-signal model of the power stage reduces from a two-pole system, created by L and COUT, to a single-pole system, created by ROUT and COUT. The single-pole system is easily used with the loop compensation. Figure 8-4 shows the equivalent small signal elements of a boost converter.
Figure 8-4 TPS61378-Q1 Control Equivalent Circuitry ModelThe small signal of power stage is:
where
- D is the duty cycle
- ROUT is the output load resistor
- RSENSE is the equivalent internal current sense resistor, which is typically 118 mΩ
The single pole of the power stage is:
where
- COUT is the output capacitance. For a boost converter having multiple identical output capacitors in parallel, simply combine the capacitors with the equivalent capacitance
The zero created by the ESR of the output capacitor is:
where
- RESR is the equivalent resistance in series of the output capacitor
The right-hand plane zero is:
where
- D is the duty cycle
- ROUT is the output load resistor
- L is the inductance
Equation 20 shows the equation for feedback resistor network and the error amplifier.
where
- REA is the output impedance of the error amplifier, typically REA = 500 M?
- ?P1, ?P2 is the pole's frequency of the compensation
- fZ is the zero’s frequency of the compensation network
where
- CC is the zero capacitor compensation
where
- CP is the pole capacitor compensation
- RC is the resistor of the compensation network
