8.2.3 SEPIC Mode Application
When LED string voltage can be above and below the input voltage level, use the SEPIC configuration. In SEPIC mode, the SW pin detects a maximum voltage equal to the sum of the input and output voltages, a consideration when selecting components.
Figure 8-6 SEPIC Mode with
Three LEDs in Series
