8.2.1.2.2 Setting Output Voltage Rise Time (tR)
The slew rate (SR) needed to achieve the desired output rise time can be calculated as:
Equation 8.
The CdVdt needed to achieve this slew rate can be calculated as:
Equation 9.
Choose the nearest standard capacitor value as 3300 pF.
For this slew rate, the inrush current can be calculated as:
Equation 10.
The average power dissipation inside the part during inrush can be calculated as:
Equation 11.
The power dissipation is below the allowed limit for a successful start-up without hitting thermal shut-down within the target rise time as shown in the Figure 8-3.
Figure 8-3 Thermal shut-down plot during inrush
