DLPU096A November 2019 – October 2025 DLP5534-Q1 , DLPC230-Q1 , DLPC231-Q1 , TPS99000-Q1
Abstract
The DLP5534Q1 Evaluation Module (EVM) is a complete electronic subsystem designed to drive the DLP5534-Q1 chipset. The DLP5534-Q1 chipset consists of the DLP5534-Q1, the DLPC230-Q1, and the TPS99000-Q1. When combined with illumination and projection optics, 405 nm and other LEDs this EVM can be used to develop an automotive grade projector for applications such as transparent window display utilizing phosphor film(s) embedded in a window.
Except for the DMD, there are no optical elements provided with this EVM. It is expected that this EVM is procured in order to mount to a custom designed projector.
The DLP5534Q1 EVM is not a production design. It is intended for evaluation only.
 |
This design incorporates HDMI? technology. |
