3 說明
TPSM8D6C24 是一款高度集成、易于使用的非隔離式直流/直流降壓電源模塊。TPSM8D6C24 提供兩個 35A 獨立輸出或單個堆疊式兩相 70A 輸出。可以堆疊兩個模塊以獲得 4 相 140A 輸出。 該器件可通過外部 5V 電源對內部的 5V LDO 進行過驅動，以實現低至 2.95V 的較低輸入電壓范圍并提高轉換器的效率。
TPSM8D6C24 電源模塊使用專有的固定頻率電流模式控制，具有輸入前饋和可選的內部補償元件，可在各種輸出電容下更大限度減小尺寸和提高穩定性。
PMBus 接口具有 1MHz 時鐘支持，為轉換器配置提供了便捷且標準化的數字接口，并且實現了對輸出電壓、輸出電流和內核溫度等關鍵參數的監控。對故障狀況的響應可設置為重新啟動、鎖存或忽略，具體取決于系統要求。堆疊器件之間的反向通道通信會啟用所有 TPSM8D6C24 轉換器，以便為單個輸出軌供電以共享一個地址，從而簡化系統軟件或固件設計。也可通過 BOM 選擇在不進行 PMBus 通信的情況下，配置輸出電壓、開關頻率、軟啟動時間和過流故障限制等關鍵參數，以支持無程序加電。
(1) 有關詳細信息，請參閱 節 10。
(2) 封裝尺寸（長 x
寬）為標稱值，并包括引腳（如適用）
簡化版應用
效率
