7.5 Fault Recovery Time
Fault recovery time (tRECOVERY) measures the delay between the source voltage falling from overvoltage condition to below fault supply voltage (VFP or VFN) plus 0.5 V and the drain voltage rising from 0V to 50% of the fault supply voltage exceeded. Figure 7-6 shows the setup used to measure tRECOVERY.
Figure 7-6 Fault Recovery Time Measurement Setup
