8.2.3.2 Application Performance Plots
| VIN_DC = 1.0 V power supply 100Ω series resistance |
| VBAT = 3.4-V charged Li coin cell |
| VIN_DC = sourcemeter with VSOURCE = 2.0 V and compliance of 43 mA |
| VBAT_SEC = sourcemeter with VSOURCE = 3.0 V and compliance of 1 A |
| VIN_DC floating |
| No storage element on VBAT or VBAT_PRI |
| VSTOR artifically ramped from 0 V to 5 V to 0 V using a function generator |
| VIN_DC = sourcemeter with VSOURCE = 2.0 V and compliance of 43 mA |
| VBAT_SEC = sourcemeter with VSOURCE = 3.0 V and compliance of 1 A |
| VIN_DC = sourcemeter with VSOURCE = 2.0 V and compliance of 43 mA |
| VBAT_SEC = sourcemeter with VSOURCE = 4.0 V and compliance of 1 A |
