8.2.3 Application Curves
The roll of characteristics and output waveform for the designed MFB filter are shown in Figure 8-4 and Figure 8-5. The attenuation is specified in Table 8-2.
Figure 8-4 2nd-Order MFB LP Filter AC Output Characteristics
Figure 8-5 2nd-Order MFB LP Filter DC OutputTable 8-2 Signal Attenuation vs Frequency
| 2ND-ORDER MFB LPF FREQUENCY (kHz) | ATTENUATION (dB) |
|---|---|
| DC | 9.54 |
| 10.0 | 9.70 |
| 15.4 | 6.54 |
| 19 | 3.54 |
| 30 | –4.38 |
| 320 | –45.9 |
